Cylinder material: SPCC steel or Stainless steel
Valve material: Brass
Working pressure: 12~18Bar
Test pressure: ≥ 25Bar
Dry powder: ABC dry chemical powder, using for solid, oil & grease, electrical
Typical bracket: Vehicle bracket
Warranty: ≥ 4 years
Product Description
Portable foam extinguishers are suitable for both Class A & B fires. Foam has the ability to reduce the risk of reignition. Foam extinguishers combine the smothering effect of AFFF and the cooling and penetrating effect of water.
| Type | 500 ml | 1L | 2L | 6L | 9L |
| Cylinder material | SS304 | SS304 | SS304 | ST12 | ST12 |
| Cylinder weight (KG) | 0.4 | 0.53 | 0.75 | 2.7 | 3.2 |
| Cylinder Capacity (L) | 0.65 | 1.3 | 2.5 | 7.8 | 11.8 |
| Worling Pressure | 14 Bar | ||||
| Test Pressure | 29 Bar | ||||
| Worling temp. | 00 C To +600 C | ||||
| Propellant gas | Nitrogen / N2 | ||||
| Decking fire rate | 3A13B C | 1A 10B C | 8A 34B C | 1113B 89B | 112B |
| Packing Size (mm) | D75*H260 | D85*H340 | D102*H420 | D160*H550 | D180*H600 |
| Total Weight (kg) | 1.12 | 1.8 | 3.1 | 9.3+/-0.1 | 13.2+/-0.2 |
| Agent | 6% AFFF |
